SONTU2000-Kirin-A is a reliable intraoral x-ray imaging plate scanner solution with a modern and elegant appearance. With its lightweight and compact system design, it can perfectly fit into any dental ofice. The device adopts computed radiography (CR) scanning technology to acquire high-quality digital images for dentists to diagnose in the clinic.
Dental Computed Radiography reader
Description
Feature
Specification
AI Dental Diagnosis
- Trained on 10,000+ dental X-rays using EfficientDet
- One-click detection of 13 dental diseases in 4 categories
Smart Guidance & Multi-Room Sharing
-
SONTU Smartlin enables seamless access across clients
-
Support for multi-room image sharing without interference
Core Imaging Power, Smarter Experience
-
Equipped with world-renowned Hamamatsu PMT for clearer, more reliable images
-
Smart scanning bay with auto-insert, light indicators, and auto plate erasure
- Compatible with 4 plate sizes for versatile clinical use
Smart Imaging Software, Effortless Operation
-
Intelligent, guided interface for quick learning and easy use
-
Built-in tools for grayscale, contrast, sharpening, zoom, and mirroring
-
Supports distance and angle measurement with auto calibration
-
Auto brightness, erasure, and cropping for streamlined workflow
Clinical Image
Features
1. Images acquisition within 10s that speed up your workflow.
2. The reuseable image plate can be recognized, scaned and erased automatically.
3. 4 optional image plate sizes are available to meet all your clinic demands.
4. Indicator light reminds the real-time work situation of the scanner.
5. Original & unique magnetic image plate box design that can be absorbed on the two sides of the host.
6. Slim and soft image plate creates comfortable patient experience.
Intended Use
The device is intended for capturing, digitization and processing of intraoral x-ray images stored on imaging plate recording media.
Intended User
The device can only be used in hospitals or clinics. The users of this equipment must be medical personnel who have obtained coresponding medical
qualifications.
Intended patient population
Adult and children over three years old.
Contraindications
None.
Note
1. This equipment can only be used in hospitals or clinics. The users of this equipment must be medical personnel who have obtained coresponding medical qualifications.
2. Users of this equipment shall receive the relevant training (on-site, video or telephone training) from the manufacturer before use.
Warning
1. Do not reuse the protective paperboard and protective jacket. Each protective paperboard and protective jacket can be used only by one patient.
2. Do not reuse the protective paperboard and protective jacket. Each protective paperboard and protective jacket can be used only by one patient.
3. Don’t near active HF surgical equipment and the RF shielded room of an ME system for magnetic resonance imaging, where the intensity of EM disturbances is high.
Specification
| Image plate dimension | 0#,1#,2#,3# |
| Dimension | 295mm (length) x140mm (width) x280mm (height) |
| Weight | <5kg |
| Power supply | 100-240V~，50/60HZ |
| lmage file format | DICOM 3.0, TIFF, BMP, JPEG |
| Working temperature | 10°C~40°C |
| For indoor use only |
